High-Production Pipe and Bolt Threading Machine

Oster 792ALX Extra Long Bed
Capacities
Bolt Range 1/4" to 2"
Pipe Range 1/8" to 2"
Capacities

Bolt Range

1/4" to 2"

Pipe Range

1/8" to 2"


General Specifications
Spindle Speeds, Variable 20-210 RPM
Maximum thread length with no re-grip
Standard Bed. 7.5"
Long Bed 15"
Extra Long Bed 25"
Net Weight 900 lbs.
Shipping Weight 1040 lbs.
General Specifications

Spindle Speeds, Variable

20-210 RPM

Maximum thread length with no re-grip

Standard Bed.

7.5"

Long Bed

15"

Extra Long Bed

25"

Net Weight

900 lbs.

Shipping Weight

1040 lbs.

Increase your efficiency and reduce production time with a heavy-duty pipe and bolt threading machine. The Oster 792A “LX series” pipe and bolt threading machine is a heavy-duty, high-production bolt threading machine.

  • Available in 3 bed lengths, the standard bed is a workhorse for pipe threading applications and most bolt threading applications with a 7-3/4” stroke length.
  • For longer bolts or long runs of NPS Pipe Threads, you can re-grip on the standard-length bed, or upgrade to a long, or extra-long bed machine with a 15” or 25” stroke.
  • Produces Class 2A threads from ¼” to 2-1/4” Bolt and 1/8” to 2” Pipe.

Oster’s commitment to quality means this threading machine is not only affordable, but it is made in the USA and made to last.

Request a Quote

Advantages of the Oster 792ALX Pipe and Bolt Threading Machine

Besides the quality and longevity of our products, Oster’s 792ALX offers the following advantages:

  • Cost-efficient when compared to CNC machining.
  • No need for a skilled operator.
  • Interchangeable.
    • Works with high-production pipe and high-production bolt in equal capacity. Because the pipe threading industry requires a keen eye, the 792ALX offers detailed accuracy for more critical applications.
  • Semi-automatic operation
  • Manufactured in the USA

Oster 792ALX Heavy-Duty Pipe and Bolt Threading Machine Features

As our flagship pipe and bolt threading machine, the Oster 792ALX is built for high-production work.

Feature

Details

Self-Centering Quick-Action Vise Carriage



  • Open type vise with hardened alloy steel gripping jaws for ½” to 2” and auxiliary jaws for diameters under 1/2".
  • This smooth working vise permits easy loading insures positive gripping and automatic centering.
  • Features an adjustable stock rest for easy loading and unloading of material.



Adjustable Diehead Threading Stop



  • Easy to change quick-setting adjustable stop automatically opens the die-head at the desired thread length.
    • The pipe & bolt machine can make repetitive cuts of the same length easy and accurate.



In Spindle Ream & Chamfer Tool Available for Pipe Threads



  • With the optional #02871 Ream & Chamfer tool the 792ALX can easily ream and chamfer the ends of freshly cut pipe threads without any extra operations.
  • It can also be used to equip a chamfer tool for solid bar stock.

Three Bed Lengths Available for the Threading Machine



  • With three bed sizes available you can find the perfect balance between maximum thread length capabilities and the footprint of your new machine.

Bed Sizes

Standard-Max thread length= 7-3/4 inches

Long-Max thread length= 15 inches

Extra Long- Max thread length-25 inches

Feature

Self-Centering Quick-Action Vise Carriage

  • Open type vise with hardened alloy steel gripping jaws for ½” to 2” and auxiliary jaws for diameters under 1/2".
  • This smooth working vise permits easy loading insures positive gripping and automatic centering.
  • Features an adjustable stock rest for easy loading and unloading of material.

Adjustable Diehead Threading Stop

  • Easy to change quick-setting adjustable stop automatically opens the die-head at the desired thread length.
    • The pipe & bolt machine can make repetitive cuts of the same length easy and accurate.

In Spindle Ream & Chamfer Tool Available for Pipe Threads

  • With the optional #02871 Ream & Chamfer tool the 792ALX can easily ream and chamfer the ends of freshly cut pipe threads without any extra operations.
  • It can also be used to equip a chamfer tool for solid bar stock.

Three Bed Lengths Available for the Threading Machine

  • With three bed sizes available you can find the perfect balance between maximum thread length capabilities and the footprint of your new machine.

Bed Sizes

Standard-Max thread length= 7-3/4 inches

Long-Max thread length= 15 inches

Extra Long- Max thread length-25 inches



Oster X1 Style Rotating Diehead for Increased Production

The Oster rotating X1 diehead allows for increased production over a standard bolt and pipe threading machine. It also creates a safer work environment because the concern over long pieces of rotating material is eliminated. It can produce up to 200 threaded ends per hour as well as cutting both right-hand and left-hand threads in a single pass.

Benefits of the Rotating X1 Diehead for High-Production Threading Machines

It’s Faster- Most threading machines rob you of production time because the operator must start and stop the spindle to insert or remove the work piece.

  • With the X1 rotating diehead the need to start and stop the spindle between work pieces is eliminated.
  • This allows for significantly higher production rates when compared to a conventional pipe or bolt threading machine.

It’s Safer- Shop safety is also improved when using the X1 rotating diehead machine.

  • With a lathe or conventional threading machine there is always a piece of rotating material that necessitates workspace headaches, especially on longer pieces.
  • With the X1 rotating diehead there is no longer a need for concern when threading long pieces of material, whether one is threading a 20” piece or a 20’ piece.

Better than a Lathe- With the X1 diehead your threads are cut in a single pass, something unmatchable with single point solutions on a lathe.

  • It is superior for tackling long thread lengths and eliminates the need for live centers that add an extra machining operation.

Niche Applications for the Oster 792ALX Pipe and Bolt Threading Machine

While the Oster line of pipe and bolt threading machines offer an unsurpassed value to many industries, the Oster 792ALX threading machine also applies to niche applications, including:

  • Anchor bolts
  • Cement anchors for construction
  • Pipe. Examples include fire sprinklers and pipes for natural gas
  • Non-standard applications like gas trucks
  • Hanger bolts for nuclear submarines
  • Snowblowers

Production Speed Studies for Pipe and Bolt Threading Machines

Pipe Threading

Pipe Size 1/2" x 6" lg. 1/2" x 2' lg. 1/2" x 10' lg. 1" x 6" lg 1" x 2' lg. 1" x 10' lg. 2" x 6" lg. 2" x 2' lg. 2" x 10' lg.
Pieces per hour 211 211 163 175 180 124 138 138 91
Pipe Size Pieces per hour
1/2" x 6" lg. 211
1/2" x 2' lg. 211
1/2" x 10' lg. 163
1" x 6" lg 175
1" x 2' lg. 180
1" x 10' lg. 124
2" x 6" lg. 138
2" x 2' lg. 138
2" x 10' lg. 91

Bolt Threading

Bolt Dia. 1/4" 3/8" 1/2" 5/8" 3/4" 7/8" 1" 1-1/8" 1-1/4" 1-3/8" 1-1/2"
Pieces per hour 220 250 215 180 187 150 157 150 150 145 130
Bolt Dia. Pieces per hour
1/4" 220
3/8" 250
1/2" 215
5/8" 180
3/4" 187
7/8" 150
1" 157
1-1/8" 150
1-1/4" 150
1-3/8" 145
1-1/2" 130

Bolts or Studs of screw stock with one inch of National Course thread cut on one end. Head turning at recommended speed.

Discuss Your Pipe and Bolt Threading Machine Needs with Us

For over 125 years, the Oster Manufacturing Company has been committed to manufacturing top-quality pipe and bolt threading machines. We are dedicated to manufacturing threading machines that exceed our customer’s expectations. This dedication can be seen through the high-quality materials we use to our priority focused on customer satisfaction.

Contact the threading specialists at Oster with your questions or custom project with us today.



See the 792ALX Threading Machine In Action

Demonstration of Threading and End Finishing Pipe with #02871 Ream & Chamfer Tool.

Basic Operation - Bolt

Basic Information for the Oster 792A Threading Machine



Let Us Answer Your Custom Applications or Technical Questions

Get technical support from pipe and bolt threading machine experts. When you call Oster Manufacturing there is always a human being on the other end of the line. We have skilled technicians and sales experts on hand to take your call.

If you’re interested in a machine or tooling for a non-standard threading application, we are happy to consult with you on the project. We can create custom engineered solutions to make your project idea a reality. We also manufacture a variety of custom tooling for special projects and keep them in stock for you. Never wait for tooling for a difficult project again.
